Description
Smaller, lighter, better – the shortest and lightest hunting riflescope with premium optics for use on the lookout or when stalking in the mountains, ever available.
The result is a powerful riflescope that measures just 27.8 cm long and weighs just 518 g . The new Ranger 4S is more than 25% shorter than comparable models from other manufacturers with a 4x magnification range.
The compact design makes the Ranger 4S 4-16×44 particularly suitable for use with additional attachments. In combination with the compact Nighthunter C35 thermal imaging attachment, handling the scope remains comfortable and simple, almost like with a classic riflescope without an attachment.
Optimized weight distribution due to the short and lightweight design improves the balance of the weapon, while the greater distance to the silencer additionally protects the attached attachment. Easy access to the attachment makes it even more pleasant to use.
No key optical or mechanical features of the Ranger 4 series are sacrificed. The XL field of view provides excellent visibility and increased safety in various situations. Steiner High-Contrast optics provide a bright, clear and contrasting image with high sharpness right to the edge, while the reliable mechanics impress with their precision and repeatability of settings.
The sleek, compact design combined with Steiner’s legendary robustness makes the Ranger 4S a versatile hunting companion, suitable for both traditional and modern hunting methods.
| Property | Data |
| OPTICAL PROPERTIES | |
| Zoom | 4–16× |
| Lens diameter | 44 mm |
| Exit pupil | 10.8–2.95mm |
| Light transmittance | 90% |
| Field of view at 100 m | 11–2.75m |
| Eye distance | 85mm |
| Diopter adjustment | –3 to +2 dpt |
| Parallax | Adjustable from 20 m to infinity |
| FUNCTIONS AND EQUIPMENT | |
| Optics | High-Contrast |
| Nitrogen filling | Yes |
| Cross | 4-AI |
| Position of the cross | 2nd focal plane (SFP) |
| Reticle adjustment step per 100 m | 1cm |
| Maximum crosshair displacement in height / direction per 100 m | ±116 cm |
| Illumination of the cross | 11 levels |
| Automatic shutdown | Yes |
| Operating temperature range | –25°C to +63°C |
| PHYSICAL PROPERTIES | |
| Length | 278 mm |
| Weight | 518g |
| Battery | CR2032 |
| Center tube diameter | 30mm |
| Lens outer diameter | 51 mm |
| GUARANTEE | |
| Warranty | 10 years |
